Crystal Quartz

Detail

　　　　　　Specifications: Material: Quartz Diameter Tolerance: +0.0, -0.1mm Wave front Distortion: l /8@ 633nm Retardation Tolerance: l /300 Parallelism: 1 arc second Surface Quality: 20/10 ClearAperture: 90% Coating: S1S2: R0.2% @ wavelength * Single　
　Specifications:
　

Material:	Quartz
Diameter Tolerance:	+0.0, -0.1mm
Wave front Distortion :	l/8 @ 632.8nm
Retardation Tolerance:	l/300
Parallelism:	<1 arc second
Surface Quality:	20/10
Clear Aperture:	>90%
Coating:	S1&S2: R<0.2% @ wavelength

Single Plate
Wide Angle Acceptance
Better Temperature Bandwidth
Wide Wavelength Bandwidth
High Damage Threshold
Thin Thickness:0.04~0.09 microns

Standard wavelength:
l/4:1480nm,1550nm
l/2:980nm,1064nm,1310nm,1480nm,1550nm
